Yulai 500KW diesel generator set
- Product description: Yulai 500KW diesel generator set
-
Yulai 500KW diesel generator set
Commonly used 500KW Guangxi Yuchai series diesel generating set specifications
Technical parameters of diesel generator set:
Unit model: GF-500
Steady state voltage adjustment rate (%): < < + 1
Rated power: 500Kw
Voltage fluctuation rate (%): < < + 0.5
Standby power: 515Kw
Transient voltage adjustment rate (%): + 20 - 15
Rated power factor: COS =0.8 (lag)
Voltage stability time (s): less than 1
Rated output voltage: 400/230V
The rate of steady state frequency adjustment (%): < < + 1
Rated current (rated / standby): 900/927A
Frequency volatility (%): less than 0.5
Rated frequency: 50Hz
Transient frequency adjustment rate (%): + 10 - 7
Rated speed: 1500rpm
Frequency stable time (S): less than 3
Start control mode: Manual
Fuel consumption (100% load): less than 195g/kW. H
Fuel number: (standard) 0# light diesel (normal temperature)
Noise (LP7m): 95dB (A)
Shape size: 4000 x 1150 x 2100 (L x W x H mm)
Unit weight: 4400kg
Technical parameters of diesel engine:
Brand / origin: Guangxi Yulai
Cooling mode: closed water circulating cooling
Model: YC6T700L-D20
Oil supply mode: direct injection
Maximum output power: 515KW
Exhaust volume: 16.35L
Number of cylinders / dares for structure: 6/L type
Speed regulation mode: high precision electronic speed regulation
Cylinder diameter travel: 145 x 165 mm
Intake mode: turbocharging
Compression ratio: 15:1
Overload capacity: 110%
Starting mode: DC24V electric boot
Speed: 1500rpm
Generator technical parameters:
Brand / origin: Shanghai master
Protection grade: IP22
Type: brushless self excited AC synchronous generator
Connection mode: three phase four wire, Y connection method
Rated power: 500kW
Regulation mode: AVR (automatic voltage regulator)
Rated voltage: 400/230V
Output frequency: 50Hz
Insulation grade: H grade
Output factor: COS =0.8 (lag)
The standard configuration of the generator set is as follows:
Direct injection internal combustion engine (diesel);
AC synchronous generator;
Suitable for environment 40 - 50 - degree radiator radiator, belt drive cooling fan and fan safety shield.
Generating power output air switch and marking control screen.
O common steel base (including: damping rubber pad for unit);
O dry air filter, fuel filter, lubricating oil filter, starting motor, and self charging generator.
Start the battery and battery starting connection cable;
9dB silencer for industrial use and standard parts for connection
Random data: diesel engine and generator original technical document, generator set instruction and unit qualification certificate.
Optional accessories (another cost):
Oil, diesel, water jacket, and anti condensation heater
The split type daily fuel tank and integral base fuel tank.
Battery charger
Rain proof unit (box)
Self protection and self starting unit control panel
Static sound set (box)
Control panel with "three remote" unit
Mobile trailer type power station (Box Trailer)
ATS automatic load conversion screen
Static sound type mobile station (Box Trailer)
Defects liability period:
(domestic) 12 months after the commissioning of the unit and 1000 hours of accumulative operation, the first maturity shall prevail.
Due to product quality problems, free maintenance or replacement is required. Lifelong service is paid.
(vulnerable parts, common parts, artificial damage, negligence, etc.) are not within the scope of warranty.
Payment method and delivery date:
Alipay, internet bank transfer, wire transfer, cash and other payment methods, delivery within 7 working days.
Implementation criteria:
International standard certification ISO9001:2000
Industry executive standard GB/T2820.1997
Distribution mode:
Door-to-door, car delivery, car stowage, etc
