Diesel Generator set

200KW diesel generator set

Product description: 200KW diesel generator set
INQUIRY

200KW diesel generator set
technical parameter
1) power range: 200KW/250KVA
2) engine model: 6126ZLD
3) generator type: Shanghai Qiang Hui brushless generator (or Standford, marathon).
4) water cooling
5) chassis oil tank (full load for 8 hours)
6) manual start / self start
7) mute / awning is optional
8) 230 / 400V AC, 50Hz / 60Hz, 0.8pF three phase four lines
9) the rate of steady state frequency adjustment: <3%
10) frequency fluctation: <0.5%
11) the rate of transient frequency adjustment: less than +10%
12) transient frequency stabilization time: less than 3S
13) steady state voltage adjustment rate: less than 1%
14) transient voltage adjustment rate: less than +20%
15) transient voltage stability time: less than 4S
16) waveform distortion: less than 0.3%
17) control system:
A) automatic alarm system (selection): the equipment is equipped with a sound and light alarm system, any of the following failures: start failure, high water temperature, low oil pressure, overspeed, overload, automatic alarm and stop when overflow.
B) monitoring instrument:
I) voltmeter, three phase ammeter, frequency meter
II) water temperature and oil pressure meter
III) oil meter, oil temperature meter
IV) alarm lights and buzzer (selection)
18) startup system: DC motor
19) short circuit protection system: MCCB plastic case circuit breaker
20) cooling system: cooling water tank to adapt to the ambient temperature of 40 degrees C when the heat demand.
21) filter: oil, diesel and air filter
22) accessories: exhaust bends, bellows, mufflers
23) allocation of supply standards:
A) the diesel engine is equipped with all accessories, 3 filters, and electronic system.
B) generator
C) steel structure chassis
D) cooling system fan and water tank
E) flange connector
F) 12 / 24V starting motor and charging motor
G) air filter, diesel filter, oil filter.
H) control panel
I) MCCB air protection switch
J) 12 / 24V starting motor and battery connection line
K) shock absorber
L) high efficiency silencer
1. Pre sale service
Professional engineers provide pre - sales technical advice and planning guidance for users, such as unit selection, matching, machine room design, etc., to solve difficult problems encountered by users in the process of use and provide relevant technical guidance.
Two. Service in the sale
After receiving the notification of the user, our company sends professional technicians to the installation site to know the installation and debugging of the unit, and do a good job with the user.
Three. After sale service
1, provide free machine room design and distribution design;
2, free guidance and installation, debugging;
3, free of charge for users of the operation and maintenance personnel for technical training and consultation;
4, guide maintenance and maintenance;
5. Establish customer files, follow up service, regular inspection and lifelong maintenance for end-users.
6, the company provides pure spare parts all year round, and the maintenance engineer can provide technical assistance to you at any time.
Quality guarantee of diesel engine
1. The warranty period: one year or 1500 hours accumulative operation (both for the first time), such as the failure of the factory assembly or the improper selection of the raw material, or other failure of the unit or other failure of the unit, can be guaranteed by the supplier.
2. Damage caused by man-made operation mistakes and negligent maintenance of the vulnerable parts and daily use accessories of diesel generating sets are not covered by this warranty. All parts and components outside the warranty period are provided at the cost price, providing the service staff to the customer site or in the factory factory to repair the unit to the normal use.
Quality assurance of diesel engine
International standard certification ISO9001
Industry standard GB/T2820.1997
Mode of payment and delivery period of diesel engine
Full payment, Alipay, internet bank transfer, wire transfer, and other payment, delivery within 5 days.
Distribution mode of diesel engine
Home lift, car delivery, car load and so on.
