Diesel Generator set
Diesel generating set of 10KW-250KW mobile power station
- Product description: Diesel generating set of 10KW-250KW mobile power station
-
Diesel generating set of 10KW-250KW mobile power station
Configuration description and related parameters of diesel generator set
Diesel engine model: R6105AZLD--R6126ZLD
Generator: Shanghai strong glow
Frequency / speed: 50Hz/1500rpm
Voltage control mode / start mode: AVR / 24V DC start up
Fuel model / oil model: 0# light diesel / 15W/40CD
Engine filtration system: dry air filter, dual fuel filter, oil filter, coolant filter.
Engine cooling mode: meet the ambient temperature 40OC radiator, belt driven cooling fan, fan safety shield.
Rated voltage / frequency / power factor / phase / line number: 400V/230V, 50Hz, COS, =0.8 (hysteresis), three-phase four wire Y type winding.
No load voltage adjustment range: > 95% - 105%
Insulation grade / protection grade: H level /IP22
Telephone influence coefficient / harmonic coefficient: TIF < 50/ THF < 2%
Frequency adjustment rate (%): less than + 0.5 (steady state) +10 ~ -7 (transient)
Voltage adjustment rate (%): less than + 0.5 (steady state) +20 ~ -15 (transient)
Voltage harmonics: less than 4%
Frequency volatility (%): less than 0.5
Voltage fluctuation rate (%): < < + 0.5
Noise LP7m:95db
Random Accessories: a set of starting batteries and connecting wires; a set of smoke exhaust elbows, corrugated shock absorbers, flanges, mufflers; a set of base shock absorbers
The first super long warranty time in the country: 1 years or 1500 hours (whichever comes first).
Mobile trailer description
It has many kinds of structure and function, including hand push, three wheel, four wheel, automobile power station, trailer power station, mobile low noise power station, mobile container station, electric power engineering car and so on.
The system is designed and manufactured by our company according to the structure of many foreign mobile power stations. It has good operation performance and safety performance. There are the following configuration options:
1. traction: adopt movable hook, 360 degree turntable, flexible steering, ensure safety in running.
2. brake: at the same time, it has reliable pneumatic brake interface and hand brake system to ensure safety during driving.
3. support: in order to ensure the stability of the power car operation, there are 4 mechanical or hydraulic support devices.
4. doors and windows: the front has ventilation windows, and the rear has opposite doors, with doors on both sides for operators to get in and out.
5. lighting: there is a ceiling mounted explosion-proof lamp in the carriage, with a worktable on the right side and a working desk lamp to facilitate the operation of the staff.
6. anti sound: the car's box, door and so on are all decorated with double decker, and it is equipped with sound absorption board, and the exhaust pipe is wrapped with thermal insulation cotton. The noise can be controlled within 75dB (A).
7. carriage size: the size of the carriage is determined according to the size of the specifications. The operator can walk around, which is convenient for operation and maintenance.
8.Exterior beauty: Paint with high polymer polyurethane paint, color can be determined by the owner, exhaust pipe using lower exhaust, to ensure beautiful.
9. fire: there are two fire extinguishers with the car. (selection)
